Hydrocracking Filters & Catalyst Bed Protection
Not every refinery will have a hydrocracker, still as demand for middle distillates such as jet fuel, kerosene, and diesel increase, refiners are finding an incentive to build them to increase distillate yield. In the low-sulfur world, the hydrocracker is part of the process of converting high-sulfur materials into low-sulfur fuels for vehicles, ships, and airplanes.
The two main chemical reactions in a hydrocracker are the catalytic cracking of heavy hydrocarbons into lighter unsaturated hydrocarbons and saturation of these newly formed hydrocarbons with hydrogen. At the same time that hydrocracking takes place, sulfur, nitrogen, and oxygen are almost completely removed, and olefins are saturated so products are a mixture of essentially pure paraffins, naphthenes, and aromatics.
Common filtration problems include particulate fouling around the process unit feed pumps and heat exchangers, carry-over hydrocarbons contaminating the recycled hydrogen compressor, carry-over lube oils from the recycled hydrogen compressor, trace hydrocarbon liquids contaminating the amine in the hydrogen recovery unit, trace water contamination in final products, etc.
|Filter Solution||Filter Purpose||Filter Benefit|
|01||Backwashable ProGuard Series filter systems or Replaceable LiquiPleat HF Series.||Removal of solid contaminants, such as scale, rust, and particulates from the hydrocracker feedstock.||Protects coalescer, prevents unscheduled reactor downtime, reduced fouling in heat exchangers extending time between maintenance and shutdowns, fewer catalyst change outs.|
|02||Phase-LOK™ or Phase-PUR™ Series Liquid/Liquid Coalescers||Removal of water from hydrocracker feedstock.||Prevents unscheduled reactor downtime, heat exchanger fouling, protection of downstream equipment, and extends catalyst bed life.|
|03||Micro-LOK™ or Micro-DEP™ Series Gas/Liquid Coalescers.||Removal of liquids and solids from recycled hydrogen.||Efficient hydrogen compressor operation and significantly reduced maintenance costs.|
|04 – 05||Micro-LOK™ or Micro-DEP™ Series Gas/Liquid Coalescers.||Removal of lube oil from compressor discharge gas.||Lower maintenance costs and improved reactor efficiency.|
|06||LiquiPleat™ Series Pleated Liquid Elements|
|Removal of solid particulates from fractionator feedstock.||Improves coalescer efficiency and protects downstream equipment.|
|07||Phase-LOK™ or Phase-PUR™ Series Liquid/Liquid Coalescers||Removal of liquid contaminants from fractionator feedstock.||Maintains fractionator efficiency by preventing contamination build up on separator plates.|
|08 – 10||LiquiPleat™ HF Series High Flow Liquid Elements and Vessels.||Removal of solid contaminants from the fractionator.||Protect liquid coalescers and downstream equipment. Maintain final product specifications.|
|11 – 13||Phase-LOK™ or Phase-PUR™ Series Liquid/Liquid Coalescers||Removal of trace water contamination from the final product.||Protection of downstream equipment. Maintain final product specifications.|
|14||Micro-LOK™ or Micro-DEP™ Series Gas/Liquid Coalescers.||Removal of trace hydrocarbon liquids from the sour process gas.||Prevention of amine contamination in the hydrogen recovery unit.|
Filtration Solutions for Hydrocracking
A big challenge for customers is maintaining the run life on catalyst beds at minimal cost.
This application requires particulate contaminant removal from the hydrocracker feed to protect the catalyst bed in the reactors.
Jonell Systems recommends pre-filtration using HORIZONTAL HIGH FLOW VESSELS with LIQUIPLEAT JHT OR JHF SERIES CARTRIDGES along with Backwashable ProGuard Series filter systems to protect the catalyst bed and reactor.
Advantages of Jonell Systems Hydrocracking Filters
- Jonell Systems offers end to end solution giving you the advantage of sourcing the complete filtration solution from one provider.
- In addition, because of the vast range of solutions and custom engineering capabilities, Jonell Systems can recommend and implement the right solution for your process.
- For the Hydrocracking application, we offer both Backwashable solutions and high flow solutions. These can be implemented based on your process needs.
- We also offer pre-filtration to optimize the efficiency of the backwash systems.
for the Refining Industry
Discuss your Application Today!
Get in touch with Jonell Systems, a part of Filtration Group, to find out more about how our filtration solutions can help you solve your filtration and separation challenges in Oil & Gas applications.
